SPECIFICATIONS

• Power Plant: Lycoming O-320-B2B

• Horse Power @ RPM: 160 @ 2700 rpm

• Seats: 2, Tandem

• Gross Weight: 1750 lbs.

• Useful Load: 550 lbs.

• Fuel Capacity: 36 gal. (35 gal. Usable)

PERFORMANCE

• Acrobatic Limit Loading: +5, -2g's

• Takeoff Distance, Ground Roll: 430 ft.

• Takeoff Distance Over 50-ft Obstacle: 895 ft.

• Demonstrated Crosswind Component: 17 kts.

• Rate of Climb, Sea Level: 1167 fpm

• Maximum Level Speed, Sea Level: 140 mph

• Cruise Speed / Endurance with 45 Min Reserve @ 75% Power: 127 mph/ 2.8 hrs

• Fuel Consumption (55% to 75% Power, per Lycoming Data): 7.3 to 10 gph

• Maximum Range (55% Power): 556 miles

• Service Ceiling: 15000 ft.

• Landing Distance over 50-ft. Obstacle: 850 ft.

• Landing Distance, Ground Roll: 480 ft.

LIMITED AND RECOMMENDED AIRSPEEDS

• VX (Best Angle): 60 mph

• VY (Best Rate): 77 mph

• VA (Design Maneuvering): 120 mph

• VNO (Maximum Structural Cruising): 120 mph

• VNE (Never Exceed): 162 mph

• VR (Rotation): 58 mph

• VS1 (Stall, Clean): 52 mph
